Aluminum Solution
AFC-Holcroft Aluminum Solution & Age Furnaces – continuous and batch systems for precision aluminum heat treatment
Product details
- Heat Treatment CapabilitySolution heat treating, artificial aging, annealing, homogenizing, stress relieving, and sand removal
- Temperature Uniformity±5 °F across all furnace configurations
- Heating SystemGas-fired or electric with optimized recirculating airflow
- Load Handling CapabilityCustom configurations for castings, forgings, stampings, and large aluminum fabrications
- System DesignModular construction for expansion and integration with automation and quench systems
Flexible configurations, superior uniformity, and fully automated handling
AFC-Holcroft aluminum furnaces combine intelligent system design with precision atmosphere and temperature control. Each system is built for performance and long life, with optional water, polymer, or air quench systems designed for optimal transfer times — as fast as seven seconds from furnace to full immersion. Automated handling, programmable controls, and SCADA integration ensure repeatability and complete data traceability.
Additional technical features
Temperature uniformity ±5 °F proven in production operation
Gas-fired or electric heating with high-efficiency recirculating fans
Modular construction for easy expansion and service access
Quench systems: water, polymer, or air with engineered agitation and recirculation
Furnace-to-quench transfer times as short as seven seconds on continuous lines
Chain conveyor or pusher-tray transport for continuous systems
SCADA and part-tracking options for full process monitoring
Turnkey installation and automation available
Key Benefits for Your Operations
Proven precision
Uniform temperature and repeatable metallurgy across all furnace types.
Process flexibility
Supports solution, age, anneal, and stress-relieve cycles.
Reduced operating costs
Efficient airflow, insulation, and optional basketless automation reduce energy use and wear.
Turnkey automation
Material handling, quench integration, SCADA control, and operator training included.
Modular scalability
Expandable construction supports production growth and process diversification.
Aluminum Solution & Age Furnace Configurations
The following table outlines key system specifications and configuration options.
| Furnace Type | Description | Typical Application |
|---|---|---|
| Roller Hearth | Continuous conveyor system for high-volume aluminum components | Automotive and aerospace wheels, engine components |
| Pusher Tray | Continuous line with precise time-to-quench control | Forgings, castings, structural aluminum parts |
| Mesh Belt | Conveyorized system for smaller parts and stampings | Fasteners, small machined aluminum components |
| Car Bottom | Batch system for large castings and complex assemblies | Aerospace structures, heavy aluminum fabrications |
| Batch / Stationary | Flexible, manually loaded system for diverse part geometries | Low- to medium-volume production |
Reliable service throughout your entire system lifecycle
We support our customers throughout the entire lifecycle of their systems – from commissioning and ongoing operation through modernization and digital integration.
FAQ – AFC-Holcroft Aluminum Solution & Age Systems
Connect With Our Team - Talk to an AFC-Holcroft Specialist
Get guidance on equipment selection, process requirements, upgrades, or technical support for your application.
